Digital exterior thickness gauge D2R20
Description
The Digital exterior thickness gauge D2R20 is an ACRN measuring instrument used for Dimensional measurement applications.
Technical information
| Opening capacity | Incrementation | Measuring force | Weight | Max permissible error | Repeatability error | Operating temperature |
| 0 – 20 mm | 0.01 mm | 0.9 – 1.6 N | 410 g | 0.040 mm | 0.02 mm | 10 – 30 °C |
Technical specifications of the Digital exterior thickness gauge D2R20: Opening capacity: 0 – 20 mm; Incrementation: 0.01 mm; Measuring force: 0.9 – 1.6 N; Weight: 410 g; Max permissible error: 0.040 mm; Repeatability error: 0.02 mm; Operating temperature: 10 – 30 °C.
For any quote request or technical information about the Digital exterior thickness gauge D2R20, contact the ACRN team using the form available on this page.
